Setting Up User Action Auditing

To set up user action auditing, use the Object Classes section on the navigation panel.

NOTE. When roles of information security administrator and application administrator are separated, the Object Classes section is available only for information security administrator.

The security manager can automatically audit operations executed by system subjects and record information about the executed operations to the access protocol. The logged operations are divided into general that can be executed with all object types, and specific that can be executed only with specific object type. Operation history can be maintained for each object type: object changes, permission changes, object deletion. If full history is maintained, object changes by all operations are saved to history.

To select object types:

In the desktop application:

Select the context menu item of objects type:

Select All. It selects all elements in the list.
Inverse Selection. It inverts the existing selection (changes list element status to the opposite).
Deselect All. It deselects all elements in the list.

Hold down the CTRL key to select specified strings.
Hold down the SHIFT key to select all strings from the current to the N string (previous selection is cancelled).

In the web application:

Hold down the CTRL key to select specified strings.
Hold down the SHIFT key to select all strings from the current to the N string (previous selection is cancelled).

After executing one of the operations, the object types will be selected for the further setup of access permissions, audit and history.

To change or view access permissions of object type:

In the desktop application:

Select the Access Permissions item in the object type context menu
Select the object type and select the Object Classes > Access Permissions main menu item
Double-click the object type name with the main mouse button.

In the web application:

Select the object.

After executing one of the operations, the Access Control Settings dialog box opens in the desktop application and the Properties side panel is displayed in the web application: Set up parameters of discretionary access control, auditing, attributes, security labels.

To turn on auditing where a set of logged operations of selected object type is determined:

In the desktop application:

Select checkboxes next to required operations on the Audit tab.

In the web application:

Click the Audit > All Operations button on the toolbar to enable all operations on the Operation Auditing tab.
Click the Audit > Common Operations button on the toolbar to enable all operations, except specific ones, on the Operation Auditing tab.
Select checkboxes next to the required operations on the Operation Auditing tab of the Properties side panel.

After executing operations, the access protocol will record operation audit of subjects by selected operations.

To disable audit of the selected object type:

In the desktop application:

Select the Turn Off Auditing context menu item of the object type.
Select the Object Classes > Turn Off Auditing main menu item
Deselect checkboxes next to the operations on the Auditing tab.

In the web application:

Click the Auditing > Turn Off button on the toolbar.
Deselect checkboxes next to the operations on the Operation Auditing tab of the Properties side panel.

After executing operations, the access protocol will turn off operation audit of subjects by selected operations.

To turn off history tracing of the selected object type:

In the desktop application:

Select checkboxes next to required operations of history tracing on the Auditing tab.

In the web application:

Click the History > All Operations button on the toolbar to enable all operations history tracing on the Operation History tab.
Select checkboxes next to the required operations of history tracing on the Operation History tab of the Properties side panel.

After executing the operations, the history of of object modifications will be executed by selected operations.

To turn off history:

In the desktop application:

Select the Turn Off History context menu item in the object type.
Select the Object Classes > Turn Off History main menu item.
Deselect checkboxes next to operations of history tracing on the Auditing tab.

In the web application:

Click the History > Turn Off button on the toolbar.
Deselect checkboxes next to the operations of history tracing on the Operation History tab of the Properties side panel.

After executing the operations, the history of object changes by selected operations will be turned off.

NOTE. On enabled history tracing, frequent changing of repository object may result in volume increase of the system table that stores history.

NOTE. Modifying permissions, turning off auditing and history is available for several selected objects.

By default, objects are displayed as a tree. When the flat view is enabled, object types are not grouped by classes.

To change the list display view, select the View > Flat View/Hierarchical View main menu item of the desktop application.

NOTE. If section parameters have been changed, an attempt to go to another section of the security manager or to close it displays a request to apply changed settings.

Adding Attributes

NOTE. Adding and editing attributes of a specific object is available only in object properties of the navigator in the desktop application. The web application provides possibility to view object attributes on the Properties side panel in read-only mode.
