Getting Started with the Reports Tool in the Web Application

To open a ready report for edit in the object navigator execute one of the operations:

Select the Edit item in the report's context menu.
Select the Edit in a New Tab item in the report's context menu.
Select the Edit in a New Window item in the report's context menu.
Select the report and press F4.

To open a ready report for view in the object navigator execute one of the operations:

Select the Open item in the report's context menu.
Select the Open in a New Tab item in the report's context menu.
Select the Open in a New Window item in the report's context menu.
Double-click the report.
Select the report and press the ENTER key.

Basic settings. They are used to rename and determine general settings of regular report opened for edit.
Main menu. It contains basic commands that are used to execute various operations with report. A report can also be saved in the edit mode.
Toolbar. It contains buttons for report building and setup in the edit mode and while working with data in the view mode.
Selection control panel. It is used to change table rows and columns on a report sheet. The panel is available if the Selection Control Panel button is clicked on the View toolbar tab. When the selection control panel is displayed, the search panel is hidden.
Side panel. It is used to select a data source and manage dimensions and also for working with report units and event handlers when editing a report.
Tab panel. It contains buttons to select a group of settings displayed on the side panel.
Controls. They are used to change table selection on a report sheet using controls when working with a ready report. The panel is available if the Controls button is clicked on the Home toolbar tab.
Parameters panel. It is used to set up report.
Search panel. It is used to find and replace data. The panel is available if the Find and Replace button is clicked on the Home toolbar tab. When the search panel is displayed, the selection control panel is hidden. The search panel is displayed for a report opened for view.
Formula bar. It is used to enter data and formulas to table cells, display addresses of selected cells and algorithm formulas if cell values are calculated by them.
Working area. It is used to build a report in the edit mode and to enter data in the view mode.
Sheet tabs. They are used to work with report sheets in the edit mode and to navigate between them in the view mode.
Status bar. It is used to display results of calculating basic aggregates of the selected table cell range.
Zoom. It is used to set up sheet display zoom in the working area.
