Getting Started with the Calculation Algorithms Extension in the Web Application

To get started with the extension, create a new or open a ready calculation algorithm.

To create a new calculation algorithm in the object navigator click the Create button in the main menu and select the object type on the New Object side panel.

To open a ready calculation algorithm for edit in the object navigator select the calculation algorithm and execute one of the operations:

Select the Edit item in the calculation algorithm's context menu.
Select the Edit in a New Tab item in the calculation algorithm's context menu.
Select the Edit in a New Window item in the calculation algorithm's context menu.
Press F4.

To open a ready calculation algorithm for view in the object navigator select the calculation algorithm and execute one of the operations:

Select the Open item in the calculation algorithm's context menu.
Select the Open in a New Tab item in the calculation algorithm's context menu.
Select the Open in a New Window item in the calculation algorithm's context menu.
Double-click the calculation algorithm.
Press the ENTER key.

To open ready calculation algorithm in the calculation mode:

Open a calculation algorithm for view.
Open a calculation algorithm for edit and click the To Calculation Mode button in the calculation algorithm's main menu.

Basic settings. In the edit mode the window contains a box for editing calculation algorithm name and also buttons to return to the object navigator, to set up calculation algorithm parameters, save and start calculation algorithm, and toggle to the algorithm calculation mode. In the calculation mode the window contains only the button for returning to the edit mode.
Main menu. It contains a list of commands and buttons that are used to open calculation algorithm in the calculation mode, to set up parameters for calculation and saving changes in calculation algorithm.

Toolbar. It contains buttons for building, setting up and starting calculation algorithm.
Parameters panel. It is used to set values of calculation algorithm parameters. To shoe or hide the parameters panel, use the Parameters button on the toolbar.
Calculation tree. It is used to set up a calculation algorithm structure. To show or hide the calculation tree, use the Calculation Tree button on the toolbar.
Working area. It is used to build calculation algorithm.
