Getting Started with the Task Scheduler Tool

To create a new scheduled tasks container:

• Select the New Object > Others > Task Container item in the Create group on the Home tab.

• Select the Task Container item in the Others submenu of the object navigator context menu.

The Scheduled Tasks Container dialog box opens.

To open a ready task container and view ready tasks in the object navigator select the scheduled tasks container and execute the operations:

• Click the Open tab on the Home ribbon tab.

• Select the Open context menu item.

• Main menu. It contains a list of commands that are used to execute various operations over tasks and scheduled tasks container.

• Toolbar. It contains commands and controls that are used to execute various operations over tasks and scheduled tasks container.

• Working area. It is used to work with tasks.

• Status bar. It displays process and result of task execution and it duplicates menu item names.

• Startup parameters. It contains task scheduler startup time and parameters, with which task scheduler was started.

• List of executed containers. It contains a list of containers executed by task scheduler.

• Control panel. It is used to check if there is a new version of configuration file and to close task scheduler window.
