MapGrid.HorizontalLinesCount

Syntax

HorizontalLinesCount: Number;

Description

The HorizontalLinesCount property determines the number of horizontal grid lines.

Comments

Property value can be set from JSON or using the setHorizontalLinesCount method.

The property is relevant if the value of the MapGrid.HorizontalLinesStepType property is PP.MapGridStepType.StepsCount.

Example

To execute the example the HTML page must contain the MapChart component named map (see Map Layout on HTML Page). Create a grid that consists of three horizontal and five vertical lines, and add it to the map:

var mapGrid = new PP.MapGrid({
    Chart: map,
    Color: PP.Color.getColor("#0033FF"), // Line color
    Width: map.getWidth(), // Grid width
    Height: map.getHeight(), // Grid height
    Thickness: 1, // Grid lines width
    HorizontalLinesCount: 5, // Number of horizontal grid lines
    VerticalLinesCount: 3, // Number of vertical grid lines
    // Create a grid using specified number of lines
    HorizontalLinesStepType: PP.MapGridStepType.StepsCount,
    VerticalLinesStepType: PP.MapGridStepType.StepsCount
});
if (!mapGrid.getIsDrawed()) {
    // Draw a grid
    mapGrid.draw();
};

After executing the example a grid that consists of three horizontal and five vertical blue lines is added to the map:

See also:

MapGrid
