The FlashBox component is a container for Flash objects. It is used to view Flash files and control Flash object properties.
| Property name | Brief description | |
 |
Align | The Align property determines behavior of the component when its parent component is resized. |
|
AlignMode | The AlignMode property determines Flash object alignment within the component. |
|
AllowDrag | The AllowDrag property determines whether an object can be dragged from the component. |
|
AllowDrop | The AllowDrop property determines whether the component can accept a dragged object. |
|
Anchors | The Anchors property returns settings that determine the percentage of the size change for the current component when the parent component is resized. |
|
BorderStyle | The BorderStyle property determines a component border style. |
|
Brush | The Brush property determines the brush that is used to fill component area. |
|
ClientHeight | The ClientHeight property is used to receive or specify the height of the component’s client area. |
|
ClientWidth | The ClientWidth property is used to receive or specify the width of the component’s client area. |
|
Color | The Color property determines a component background color. |
|
ComponentCount | The ComponentCount property returns the number of child components. |
|
Components | The Components property returns the child component. |
|
Cursor | The Cursor property determines the look of the cursor over the component. |
|
Data | The Data property is used to store any custom data. |
|
EmbedMovie | The EmbedMovie property determines whether the FlashBox component contents is saved to the database on form compilation. |
|
Enabled | The Enabled property determines whether the component is available for the user. |
|
Focused | The Focused property returns True if the focus is set on the component. |
|
Font | The Font property determines the set of characteristics describing the font that is used to display text. |
|
FrameNum | The FrameNum property determines the number of currently displayed frame. |
|
Height | The Height property determines component height. |
|
HelpContext | The HelpContext property determines a unique index for the context help section for this component. |
|
Hint | The Hint property determines a component tooltip text. |
|
Left | The Left property determines the coordinate of the left border of the component. |
|
Loop | The Loop property determines whether Flash object playback is looped. |
|
Movie | The Movie property determines the path to the file of the Flash object. |
|
Name | The Name property determines a component name. |
|
OleObject | The OleObject property returns the object placed into the FlashBox container. |
|
Parent | The Parent property determines a parent component. |
|
ParentColor | The ParentColor property determines whether the component inherits the color of the parent component. |
|
ParentFont | The ParentFont property determines whether the component uses the font of the parent component. |
|
ParentShowHint | The ParentShowHint property determines whether a tooltip is displayed. |
|
PercentLoaded | The PercentLoaded property returns the percent of loading of the Flash object. |
|
Playing | The Playing property returns whether a Flash file is being played. |
|
PopupMenu | The PopupMenu property determines the context menu to be displayed on right-click on the component. |
|
Quality | The Quality property determines the quality of Flash object image. |
|
ReadyState | The ReadyState property returns the state of the readiness of a Flash object. |
|
ScaleMode | The ScaleMode property determines the scale of displaying a Flash object. |
|
Scrolls | The Scrolls property returns parameters of component's scrollbars. |
|
ShowHint | The ShowHint property enables and disables showing a component tooltip. |
|
TabOrder | The TabOrder property determines the component position in the tab order. |
|
TabStop | The TabStop property determines whether the component is focused when the TAB key is pressed. |
|
Tag | The Tag property is not used by the compiler. The user can change the value of the Tag property and use it as he wishes. |
|
Text | The Text property determines the row identifying a component for the user. |
|
Top | The Top property determines the coordinate of the top border of the component. |
|
TotalFrames | The TotalFrames property returns the total number of frames of the object loaded into the container. |
|
Visible | The Visible property determines visibility of the component during execution. |
|
Width | The Width property determines component width. |
| Method name | Brief description | |
 |
Back | The Back method rewinds the Flash object one frame back. |
|
BringToFront | The BringToFront method brings a component to front. |
|
CallFunction | The CallFunction method executes the function implemented in the loaded Flash object and returns execution result. |
|
ClientToScreen | The ClientToScreen method converts the coordinates of a point specified relative to the component coordinate system into screen coordinates. |
|
DoDragDrop | The DoDragDrop method enables the user to start dragging operation. |
|
Forvard | The Forward method forwards the Flash object one frame forward. |
|
GetImage | The GetImage method returns the image of the component with all the child components. |
|
GetVariable | The GetVariable method returns the value of the specified variable used within the Flash object. |
|
LoadFromStream | The LoadFromStream method loads the Flash object from the stream. |
|
Pan | The Pan method moves the area displayed in the FlashBox component to the specified coordinates. |
|
Play | The Play method starts Flash object playback. |
|
Rewind | The Rewind property rewinds the Flash object to the zero frame. |
|
SaveToStream | The SaveToStream method saves the Flash object to the stream. |
|
ScreenToClient | The ScreenToClient method converts screen coordinates of a point into coordinates specified relative to the component coordinate system. |
|
SendToBack | The SendToBack method sends a component to back. |
|
SetFocus | The SetFocus method sets focus to this component. |
|
SetVariable | The SetVariable method sets the value for the specified variable used within the Flash object. |
|
SetZoomRect | The SetZoomRect method adjusts the size of the Flash object to fit the FlashBox component. |
|
Stop | The Stop method stops playing a Flash object. |
|
Zoom | The Zoom method sets the scale of a Flash object. |
| Event name | Brief description | |
 |
OnBeginDrag | The OnBeginDrag event occurs for a component when the user starts to drag an object from the component. |
|
OnClick | The OnClick event occurs if the user clicks the component area with the main mouse button. |
|
OnDblClick | The OnDblClick event occurs if the user double-clicks a component area with the mouse button. |
|
OnDragDrop | The OnDragDrop event occurs for the component if the user drops a dragged object over it. |
|
OnDragEnter | The OnDragEnter event occurs when a dragged object crosses the borders of this component. |
|
OnDragLeave | The OnDragLeave event occurs when a dragged object leaves the borders of this component. |
|
OnDragOver | The OnDragOver event occurs for the component when the user drags an object over it. |
|
OnEnter | The OnEnter event occurs when the component receives focus. |
|
OnExit | The OnExit event occurs when the component loses focus. |
|
OnHScroll | The OnHScroll event occurs when horizontal scrollbar slider changes its position. |
|
OnFSCommand | The OnFSCommand event occurs when the Flash object receives a command. |
|
OnKeyDown | The OnKeyDown event occurs if the component is focused and the keyboard key is pressed. |
|
OnKeyPress | The OnKeyPress event occurs if the component is focused when the user presses a character key. |
|
OnKeyPreview | The OnKeyPreview event occurs prior to each event related to key pressing. |
|
OnKeyUp | The OnKeyUp event occurs if the component is focused and the user releases any button previously pressed. |
|
OnMouseDown | The OnMouseDown event occurs if the pointer is in component's area and a mouse key is pressed. |
|
OnMouseEnter | The OnMouseEnter event occurs when mouse cursor enters the component area. |
|
OnMouseHover | The OnMouseHover event occurs when mouse cursor is held in the component area. |
|
OnMouseLeave | The OnMouseLeave event occurs when mouse cursor leaves the component area. |
|
OnMouseMove | The OnMouseMove event occurs on moving the cursor over component. |
|
OnMouseUp | The OnMouseUp event occurs on releasing mouse button when the cursor is in component area. |
|
OnMouseWheel | The OnMouseWheel event occurs if the component is focused when the mouse wheel is rotated. |
|
OnProgress | The OnProgress event occurs during playing of the Flash object. |
|
OnReadyStateChange | The OnReadyStateChange event occurs during changing of the Flash object readiness statte. |
|
OnVScroll | The OnVScroll event occurs when vertical scrollbar slider changes its position. |
